Product Profile of High Precision, High Speed, 2 Point Presses For Precision Parts And Lamination Stampings
Unitech Metalstamping Technologies Pvt. Ltd is engaged in manufacturing of High Precision, High Speed, and 2 Point Presses for Precision Parts and Lamination Stampings. The High Precision, High Speed, 2 Point Presses for Precision Parts and Lamination Stampings falls in the category of Apex series. This machine comes with dual plunger with four post guides. The capacity of this machine ranges from 30 to 300 tones with speeds up to 1400 speeds per minute. The High Precision, High Speed, 2 Point Presses for Precision Parts and Lamination Stampings is specially designed for high speed stamping of precision parts from connectors, terminals, to Motor Laminations.
Key Features of High Precision, High Speed, 2 Point Presses For Precision Parts And Lamination Stampings
- 4 Point Crank Support & Hydro-Dynamic Bushing
- Hydro-dynamic bushings
- Higher Thrust loads
- Decreased Friction
- Suppressed heat expansion
- Higher wear resistance
- 2-Set Frame of Cast Iron Ensures-Verticality
- The guiding holes are cast and then machined at the same time
- Guiding System of Slide& Hydro-Static Bushings
- Dual plungers bear more upward eccentric load during stamping
- 4 guide posts with hydro-static bushings can maintain the slide in the center and make clearances smaller
- Separated Clutch and Brake
- The torch of separated clutch & brake is bigger, so braking time and angle get less. Balanced load at two side can reduces wear of bearings. If mechanical parts fail at clutch or brake, press stops immediately
- Slide Quick Lift Mechanism
- The height of slide quick lift is 70 mm. It helps to solve tooling problems such as material sticking, tool jamming, scrap pulling or punch changing, quickly
- After trouble shooting, return the slide to its original height by the push of a button, and the B.D.C. is maintained without readjusting
- Colorful Computer Control System
- Colorful TFT-LCD screen display enables easy operation
- Memory includes running hours, die height, speed, pitch, and feed-height
- Auto adjustment of press parameter and slide position to save time while mounting tools and setting on press
- Temperature, air & oil pressure, motor current and so on are all displayed on screen
- All operations are recorded in the system memory
- Colorful automatic computer control system
- Anti-vibration air type cushion [Apex 30-60]
- Slide adjust motor[0.01mm]
- Front-rear safety door
- Joint for air gun x 1
- MIS-feed joint x 4
- Material-end joint x 1
- Batch, Cam joint x 5
- Inverter
- Slide quick lift [not available for knuckle]
- Anti-vibration spring type cushion [Apex80-220]
- Die arm [Apex60-220]
- Die lifter [Apex80-220]
- Gripper Feed
- Knuckle-Link Structure
- Gear Change Roll Feed
- Straightener [Lamination]
- Dual Head Un-coiler [Lamination]
