Product Profile of Monel Alloy
Steel Mart supplies Monel Alloy. Steel Mart is an ISO 9001-2000 certified company.
Monel Alloy has Density: 8.83 [gm/cc], Melting Point Range: 2370-2460 degree F, Curie temperature: 20-50 degree F and Modulus of Elasticity. This alloy also features Tension 26.0, Compression 26.0 and Torsion 9.5.
Monel is a high tensile strength nickel-copper alloy that was discovered in 1905. It was found to be highly resistant to atmospheric corrosion, salt water, and various acid and alkaline solutions. Alloy 400 can be magnetic depending upon composition and previous work history. Alloy K-500 has added aluminum and titanium for age hardening. It is totally non-magnetic and spark resistant.
Monel Alloy K-500 is used for gyroscope application and anchor cable aboard minesweepers. It is also used for propeller shafts on a wide variety of vessels and exhibits high fatigue strength in seawater. There is also application in chemical process for handling of organic acids, caustic and dry chlorine.
Monel 400 is used for marine engineering, chemical and hydrocarbon processing equipment, valves, pumps, shafts, fittings, fasteners, and heat exchangers.
Typical Analyses:
Impurities in percent
Alloy 400: Ni 66.5, Fe 2.50, Mn 2.0, Si .50, Cu 31.0, S .024
Alloy K-500: Ni 66.5, Fe 2.0, Mn 1.50, Si 0.5, Al 2.7, Ti 0.5
